VTX5848 Lite 48CH 5.8G 25-600 mW FPV VTX, OSD

The Mini VTX5848 LITE Transmitter with high power transmitting and exquisite workmanship that can be connected to most FPV camera. It's perfect for mini drone and RC hobbyist.

Features:

• Perfectly corresponds to mainstream flight controllers
• The output power is stable, the transmission distance is far
• Small size, 48 channels value, MMCX (transfer to SMA extension cable)
• Powerful power chip, up to 27V input, output 5V / 1A
• low ripple, low interference 4 fast power switches, the current launch power
• 25mW/200mW/400mW/600mW switchable (only 25mW allowed in EU!)

Specifications:

• Item name: VTX5848 LITE
• image transmission module Input voltage: DC 7V-27V
• Input current: 16.4V (4S) 600mW = 360mA ± 10mA
• Output voltage: 5V DC 1A
• Power: 25mW, 200mW, 400mW, 600mW
• The signal channel: 48 channels
• Antenna Interface: MMCX (transfer to SMA extension cable)
• Dimensions: 36 * 26 * 6mm Hole: 30 * 30mm
• Item weight: About 7g (does not include the antenna and plug line)
• Frequency switching: manual button / OSD (at the same time support)

Kindly reminder: There could be a few deviations due to manual measurement. Thank you for your attention

Package list: 1 * FPV Transmitter 1 * Antenna Transfer Cable 1 * Plug Line
