Walkera FE15 ZHUN Firefighting Drone, 30xoptical zoom, LiDAR

With the development of society, urban high-rise buildings have become a common form of architecture. The high-rise buildings bring great challenges to fire rescue. Fire equipment is unable to arrive at fire location and control it quickly due to the high-rise buildings. In order to solve this problem, Walkera designed the FE15 firefighting UAV, It possesses the ability of a large payload, strong wind resistance and high precision dropping. It can also launch a fire extinguishing projectile in a complex fire environment.

Zhun is a special firefighting drone with a foldable fuselage, a heavy payload, and is tested and approved for firefighting use. It can quickly arrive at the site, observe the fire with camera, and launch the fire extinguishing projectile, spray ABC powder/foam water or drop fire fighting ABC bombs.

Download PDF brocuhere of the ZHUN

• 30X optical zoom camera

• Super-long distance

• inspect the operation site

• 35mins flight time

• Long flight time and easy operation

• 13 KGS Payload

• Heavy payload, fast speed

• Night vision targeting system

• Aloft fire, Precision strike

Fire extinguishing bomb with night vision targeting system

The ultra-strong load and anti-tremor design, with the high magnification telescope and the high frame rate night vision camera, have high launching precision. it can launch the fire extinguishing projectile accurately in the complex fire weather environment.
The real-time target control points are displayed on the ground control points, which greatly improves the accuracy of shooting and improves the efficiency of rescue

• Fire extinguisher maximum range: 40 meters
• Extinguishing agent type: ABC Superfine dry powder
• Single shooting area covering of 9 cube meters
• Night vision targeting system, APP Cross Aiming Star

Infrared obstacle avoidance

FE15 firefighting drone uses infrared TOF technology, it can recognize obstacle 5m away in the front and then stop fly forward by intelligent obstacle avoidance system which works under high-precision sensors.

30X optical zoom camera

The standard package comes with 30X optical zoom camera. It can monitor fire location in detail over a long distance, then help you to make a correct rescue plan. You can load different types of equipment according to different needs, like Infrared thermal imaging camera and low light night vision camera.

Folding body design

The machine’s arms are designed with four axis transverse folding and embracing structure, and its structure is compact and firm. After folding, the whole machine is embraced, reducing the occupied area of the aircraft, saving the time of assembly for the staff to reduce the difficulty of packing, and greatly reducing the requirements of the transportation tools.

Heavy payload, long flight time

Powerful co-axial X8 design, which is compact, but can have up to 13kg payload. It can carry a fire-extinguishing projectile and other rescue equipment. It has a high-performance and high-energy-density power battery equipped with a battery management unit. The maximum load flying time can reach 35 minutes.

• 35 minutes flight time

• 13 KGS Max payload

• APP Cross Aiming Star

Aircraft

Gimbal and Camera

Remote

Fire extinguisher parameters

Shoot machine parameter

Download FE15 brochure (PDF file)
