DualSky:n uusi viidennen sukupolven EA moottorisarja on huippulaatua ja ne ovat poikkeuksellisen kevyitä tarkan työstönsä takia. Moottoreissa japanilaiset laakerit ja valmistuksessa on käytetty parhaita materiaaleja.
Uudessa EA sarjassa moottorien tehot ovat nousseet n. 10-20 % ja hyötysuhde 3-5%.
Features:
Improved front cover, better heat dissipation
Rotor with more beautiful star design
Increased the rigidity of the rotor and shell, reduce vibration, can withstand more loads.
Adopt tile magnets with higher grade
Higher efficiency laminations
Reduce the air gap of the stator and rotor, increase efficiency
Thicker high temperature enameled wire, improved insulation and impact resistance
Compare EA with CA at same level, the power increased 10-20%, and efficiency increased 3-5%.
More options for KV value, suitable for practical use
Add XM2838EA, XM4255EA which models CA do not have.
Motor mounting holes and shaft diameter compatible with CA Series
Accessories compatible with the CA series (except for new models)
8mm propeller mount with the thinner threads, propeller not easy to loose.
Specification:
Description: XM5060EA-9
KV: 315RPM/V
Alias(Stator diameter, Magnet length): 4130
Weight: 378g
Diameter: 49mm
Length: 58mm
Diameter of Shaft: 6.0mm
Mounting holes pitch: 30/30mm
Slots,Poles: 12,14
Idle Current(Io) @10V: 1.2A
Resistance(Ri): 32mOhm
Cruising power[8 mins]: 929W
Bursts current[15s]: 57A
Peak power[15s]: 1690W
Recommended ESC: XC9036HV
Setup 1(No. of Cell, Prop.): 8S, 16x8
Setup 2(No. of Cell, Prop.): N/A
Max. weight of sport models: 4.6kg
Max. weight of 3D models: 3.1kg
Memo: ".75-.90 2-stroke Up to .110 4st"
